HNF Nicolai XD3 All-Terrain TR MTB e-bike (27.5" | 625Wh | red)

HNF Nicolai XD3 All-Terrain TR

The XD3 is a comprehensively equipped powerhouse in the premium e-bike segment. It is ideal for anyone who wants to enjoy extended off-road tours in addition to their daily commute. In fact, an e-mountain bike also for the city, we have designed the XD3 to be consistently high-quality and low-maintenance: Instead of a chain, it has the Gates Carbon Drive, and instead of a gearstick, we have given the XD3 the enviolo TR continuously variable transmission (Rohloff SPEEDHUB 500 e-14 optional). This gives the XD3 an unprecedentedly long-lasting drivetrain, which can handle tens of thousands of kilometres without maintenance or special care.

Effortlessly and without significant wear, it can even cope with the enormous 85 Nm torque of the most powerful motors from BOSCH (4th generation "2022"), which we already install in the basic equipment. We consistently complement these with the largest Bosch battery available with 625 Wh. With the Dual Battery Option, the energy supply even increases to a huge 1125 Wh. This makes more than 300 kilometres at a stretch possible. Equipped like this, the XD3 leaves nothing to be desired.

The slim Supernova lighting system and the Wingee mudguard luggage rack underline the minimalist design signature. Pure understatement from the house of HNF-NICOLAI.

Includes ABUS Bordo 6015/90 folding lock

The innovation for all bikers, whether recreational or professional, the Abus Bordo 6015/90 folding lock is the ideal combination of resistance, weight and transport size. The joint design offers maximum flexibility and reduces the size while maintaining a high level of security. With ABUS Security Level 10, it offers good protection for medium theft risk and is recommended for securing good two-wheelers.
Technology:

• For e-bikes (only for Bosch Downtube Battery 2. Generation)
• High convenience - one key for lock and battery
• Quality cylinder at the highest security level
• 5mm thick rods, with extra soft 2-component coating to protect against paint damage
• Colour-coordinated silicone cover for the lock body with "soft touch" properties
• ABUS Plus cylinder for high protection against manipulation, e. g.B. The bars and the housing are made of specially hardened steel
• Easy to transport thanks to the practical holder
• The larger the length dimension, the easier it is to connect to a lock, the easier it is to connect it to a fixed object

Details

Enviolo TR
enviolo from Fallbrook Technologies is the standard when it comes to continuously variable gears for e-bikes. As the successor to the NuVinci N380, the enviolo TR offers ideal comfort for every riding style and terrain with a wide gear ratio of up to 380%.

Bosch Performance CX
With only 2.9kg and a 48% reduction in size, the new Bosch CX motor is the new benchmark for mid-mounted motors. It accelerates extremely powerfully, reacts without delay and now supports with up to 340% (4th generation). Its new gear concept significantly reduces pedalling resistance when the drive is switched off, so that a natural riding feel is achieved even above 25 km/h.

• Up to 340% assistance for steep climbs
• Full power development from a standstill
• Powerfully supports a wide cadence range
• Minimal pedalling resistance above 25 km/h or in off-mode
• .mode
• Reduced wear thanks to high-precision motor control
• eMTB mode for maximum traction and optimal control
• Powerful push assistance on uphill passages

In keeping with the philosophy of HNF-Nicolai, the enviolo is completely maintenance-free. Unlike conventional gear hubs, it can also be shifted under load or when stationary. With these advantages, the enviolo TR is a very good choice for the majority of all e-bike riders. We therefore install the enviolo TR as standard on the XD3 All Terrain, unless another gearbox is requested.

Intuvia Active
We install Intuvia Active as standard on the XD3. Simple, intuitive and safe operation on the separate control unit and a large display characterise this on-board computer. Not only switching between the five riding modes plus push assist, but also retrieving information such as speed, charging status, distance and much more could not be easier. In addition, the shift recommendation shows the optimal moment to change gear by means of an arrow display.

RockShox Recon
The Recon by RockShox is the ideal suspension fork for the XD3 Premium e-Bike: it combines low weight with an extremely stiff chassis. With the particularly strong RockShox steel stand tubes, it allows for a large suspension travel of 120mm. Thanks to Motion ControlRL damping, this makes the RECON the new reference for ultimate riding fun.

Gates Carbon Drive
What better way to power an e-bike than with technology that originated in high-horsepower motorbikes and dragoons? None! And that's why we chose the Gates Carbon Drive for the development of the HNF-Nicolai e-bikes. Because the belt drive developed by Gates Corp. is a high-performance technology that has been perfected for e-bikes. It consists of two metal pulleys and a high-strength belt embedded in carbon fibre cables.

And the best thing for everyday cycling: the carbon reinforced belt drive is practically maintenance-free. A little water on it every now and then to get the dirt off - on it goes. And it lasts up to four times longer than a chain drive.

In addition, the polyurethane coating guarantees absolute resistance to rust. The stretch-free carbon fibre technology makes the belt 20% lighter and lasts up to 10 times longer than any chain. Your e-bike runs absolutely reliably, silently and cleanly with this belt drive. With an 11 mm pitch, the Gates CDX belt drive meets every requirement. The patented system ensures smooth meshing of the teeth - for a powerful and efficient riding experience. Whether powerfully pedalling uphill or riding smoothly in city traffic.

The advantages of the Gates belt drive for your e-bike pleasure

• Clean belt drive: No lubrication. No grease stains. The Gates Carbon Drive is dirt-repellent and can easily be cleaned with water.
• Quiet belt drive: No chain. No chain running noise.
• Lightweight belt drive: No metal. No weight. The Gates Carbon Drive weighs 20% less than a classic chain drive.
• Powerful belt drive: No friction. No wasted power. The direct power transmission and frictionless drive release power.
• Robust belt drive: No stretching. No defect. Thanks to the stretch-free carbon fibre technology, the belt drive has a four times longer service life than a classic steel chain.

PowerTube 625Wh
For the highest demands on performance and aesthetics: Bosch PowerTubes power every tour full of energy and, thanks to their compact size and minimalist design, fit ideally into the design of the e-bike. The sophisticated battery management system of the lithium-ion batteries, which can be integrated into the frame, ensures maximum service life, and a safety device prevents them from falling out even in demanding terrain. The batteries can still be conveniently removed.

• Voltage: 36 V
• Capacity: 16.7 Ah
• Energy content. 625 Wh
• Weight: approx. 3.5 kg
• Size: 416 x 84 x 65mm (horizontal), 416 x 65 x 84mm (vertical)

Supernova Mini 2
The extremely compact design of the Supernova MINI 2 uses the new Terralux3 lens. The brightness has been increased to over 15% percent and is now 235 lumens. The built-in overvoltage protection in combination with a soft start when switched on ensures a long service life for the MINI 2. Thanks to sophisticated light control, the Terraflux lens directs 90% of the light to where it is needed most: on the road.
