Details
HNF Nicolai XD4 All-Terrain E-Bike
The superior torsionally stiff frame is the heart of our XD range. Always equipped with the largest 750 Wh battery from BOSCH, we manufacture the XD in uncompromising HNF quality. "All Terrain" is the universal pedelc for city and country. It comes with HNF's typical combination of carbon belt and continuously variable transmission. We have comprehensively equipped it with the most popular components of the upper premium segment.
A timeless and reduced design language has always been a central feature of our bikes, which are as robust as they are manufactured to a high standard. At the same time, HNF today symbolises the pioneering achievements with which we drive our advanced drive concept forward: We prefer to combine the powerful and indestructible Bosch motors with a durable belt drive and a continuously variable transmission. This combination, which we first introduced in 2015 with the XD series, is now regarded across manufacturers as the gold standard of maintenance-free.
Includes ABUS Bordo 6500/120 Granit Xplus folding lock
The innovation for all bikers, whether recreational or professional, the Abus Bordo 6500/120 folding lock is the ideal combination of resistance, weight and transport size. The joint design offers maximum flexibility and reduces the size while maintaining a high level of security. With ABUS Security Level 10, it offers good protection for medium theft risk and is recommended for securing good two-wheelers.
Technology:
- For e-bikes
- High convenience - one key for lock and battery
- Quality cylinder at the highest security level
- 5 mm thick rods, with extra soft 2-component coating to protect against paint damage
- Colour-coordinated silicone coating for the lock body with "soft touch" properties
- ABUS Plus cylinder for high protection against manipulation, e. g.B. picking
- The bars and the housing are made of specially hardened steel
- Easy to transport thanks to practical holder
- The longer the length, the easier it is to connect to a fixed object
details
Bosch Smart System Performance CX
With only 2.9 kg and a 48 % reduction in size, the latest Bosch CX motor is the undisputed benchmark among mid-range motors. It accelerates extremely powerfully, reacts without delay and now supports with up to 340 % of the pedal force used. Its new transmission concept reduces pedalling resistance to a minimum, so that a natural riding feel is achieved even above 25 km/h or when the motor is switched off. The Performance Line CX is a powerful and dynamic drive for intuitive handling and a unique riding experience. It goes with you to the limit - for even more riding pleasure on technically demanding terrain. In the smart system, the Drive Unit is fully networked with the other components of your eBike. Via the eBike Flow app, you can use digital features such as Activity Tracking and eBike Lock and keep your eBike up to date in the future.
BOSCH Intuvia Display
The Intuvia Display from BOSCH is fitted as standard on the UD3. Simple, intuitive and safe operation on the separate control unit and a large display characterise this on-board computer. Not only switching between the five riding modes plus push assist, but also retrieving information such as speed, charging status, distance and much more could not be easier. In addition, the shift recommendation shows the optimal moment to change gear by means of an arrow display. Not only shifting between the five riding modes plus push assist, but also retrieving information such as speed, charge status, distance and much more could not be easier. In addition, the shift recommendation shows the optimal moment to change gear by means of an arrow display.
Supernova Mini 2
The unique Terralux3 lens is used in the extremely compact housing of the Supernova MINI 2. The brightness is 235 lumens. The built-in overvoltage protection combined with a soft start when switched on ensures a long service life for the MINI 2. Thanks to sophisticated light control, the Terraflux lens puts 90% of the light where it is needed most: on the road.
More Information
| Brand | HNF |
|---|---|
| Genuine number | 102301160 |
| Weight | 30 kg |
| Permissible total weight | 150 kg |
| Bicycle type | E-bike / pedelec |
| Licensing/registration required acc. to road traffic regulations? | No |
| Colour | Black |
| Frame Shape | Trapez |
| Frame design | Hard tail MTB frame |
| frame material | Aluminium |
| Engine manufacturer | Bosch Performance CX | 250W | 85Nm | 36V | 25km/h |
| Battery | Bosch PowerTube | 36V | Lithium-Ionen | 750Wh |
| Charger included? | Yes |
| Display | Bosch Kiox 300 |
| fork type | suspension fork |
| Fork | RockShox Recon Silver RL Solo Air | 15x120mm | konisch |
| Shifting system type | Enviolo CVP TR |
| Shift lever | Enviolo Drehgriff CT Twist Pure |
| Cassette | Gates CDX | 55 Zähne | mit Bashguard |
| Crankset | Miranda Delta | 170mm |
| Chain | Gates CDX Riemen | 122 Zähne |
| Handlebar type | Ergotec Low Riser Bar I | 740 mm | 12° |
| Stem | Ergotec Sepia XL FI 50 | 90 mm |verstellbar |
| Grips | Ergon GP10-L | schwarz |
| Saddle | Selle Royal ON Moderate |
| Seat post type | Ergotec Atar | 31,6mm |
| Brake | Magura MT5 | 203mm |
| braking system | Hydraulic disk brake |
| Brake (Rear) | Magura MT4 | 180mm |
| Rear brake technique | Hydraulic disk brake |
| Coaster brake | No |
| Front hub type | Shimano HB-MT410-B |
| Rear hub type | Enviolo CVP TR |
| Rims | Ryde Andra Disc | 584-29 |
| Rim size | 27.5 inches |
| Tyres | WTB Groov-E FG | 62-584 | Reflex |
| Pedals model | VP Components VPE-527 |
| Headlight | Supernova Mini 2 |
| Rear light | Supernova M99 TL3 Pro Max | mit Bremslicht und Notbremssignal |
| Rack | Racktime für HNF | max 25kg |
| Mudguards | HNF Aluminium Multi Cavity Extrusion |
| Kickstand | Pletscher Optima Flex |
| Additional accessories | Abus Bordo 6500/120 Fahrradschloss |
| Size chart | M - 45 cm L - 49 cm XL - 53 cm |
| Please note: | Der Hersteller behält sich vor, einzelne der abgebildeten Komponenten durch gleich- oder höherwertige zu ersetzen, so dass das Fahrrad entsprechend abweichend ausgeliefert wird. Der Einsatz anderer Komponenten ist bspw. Lieferproblemen geschuldet. |
