Do you love spontaneous adventures and are looking for a reliable trekking eBike to accompany you? Our new 2023 Yucatan X12 is perfect for exploring the city or the countryside. With its completely revised frame design and a new motor, it not only looks more dynamic, but now offers you even more power on the road: The Yamaha PW-X3 motor supports you with up to 85 Nm when you're going uphill for a longer time or when you're riding with luggage - which you can easily attach to the rear rack. Additional accessories can be easily mounted via the Modular Rail System. High-quality Shimano Deore shifting components, well-controlled Shimano disc brakes and the 100 mm suspension fork from RockShox ensure that you can fully focus on your surroundings.
Brand | Winora |
---|---|
Permissible total weight | 150 kg |
Bicycle type | E-bike / pedelec |
Licensing/registration required acc. to road traffic regulations? | No |
Colour | Blue |
Frame Shape | Diamant |
Frame design | Hard tail MTB frame |
Frame features | Aluminium | Steckachse M12 (1.00) x 148mm | Scheibenbremse Post Mount |
Engine manufacturer | Yamaha PW-X3 | 250W | 85Nm | 25km/h |
Battery | InTube | 720Wh |
Display | Yamaha Side Switch |
fork type | suspension fork |
Fork | RockShox Recon RL Remote Lockout | Luft | 100mm | Stahlschaft 1 1/8" - 1 1/2" konisch |
Number of gears | 12 |
Shifting system type | Shimano Deore M6100 |
Shift lever | Triggerschalter |
Cassette | Shimano M6100 | 10-51 Zähne |
Crankset | Stahl | 38 Zähne |
Chain | Shimano M6100 |
Handlebar type | Ergoriser | oversize | 720mm |
Stem | XLC A-Head verstellbar | A-Head | 31.8mm |
Headset | A-Head | Konisch |
Grips | Ergonomische Griffe |
Saddle | Selle Royal Essenza |
Seat post type | Patent | 34.9mm | Aluminium |
Brake | Shimano MT420 | Aluminium | 203mm |
braking system | Hydraulic disk brake |
Brake (Rear) | Shimano MT420 | Aluminium | 180mm |
Rear brake technique | Hydraulic disk brake |
Rücktrittbremse | Nein |
Brake lever type | Shimano MT401 | Aluminium |
Front hub type | Shimano MT400-B |
Rear hub type | Shimano MT410-B |
Rims | Schürmann Yak25 | geöst | Hohlkammerfelge | Aluminium |
Rim size | 27.5 inches |
Spokes | Sapim Leader | Schwarz |
Tyres | Schwalbe Johnny Watts | 60-584 | Reflex |
Pedals model | VP E461 Aluminium | mit Reflektor |
Headlight | Herrmans H-Black MR8 | 60 Lux |
Rear light | Spanninga Aerline 2.0 Brake |
Schutzbleche | Curana Apollo 70 | Aluminium |
Fahrradständer | Ursus Mooi | einstellbar |
