Focus Jam² 8.7 Fully MTB e-Bike (29" | 625 Wh | gray)



Focus Jam² 8.7

JAM² 8.7 Features

  • Bosch Smart System with Performance CX e-drive, System Controller with Mini Remote control and 625 Wh battery.
  • 160 mm travel DVO Diamond E3 suspension fork and 150 mm F.O.L.D. kinematics with RockShox Deluxe Select shock.
  • Fully integrated C.I.S. cable routing with trail-ready SRAM NX Eagle 1x12 shifting.

Conquers new mountains

  • Super powerful and dynamic Bosch Performance Line CX e-drive system

Thanks to the Bosch Performance Line CX drive system, you can ride even more trails in the same amount of time. The powerful drive unit supports you with up to 85 Nm of torque and ensures fun even uphill. Even if the motor gives you full backing, your JAM² 8.7 can still be controlled playfully, even on the most challenging trail passages. The Slide-Out battery with 625 Wh can be charged via the integrated charging socket on the seat tube of the E-MTB. Alternatively, you can also remove the battery easily and quickly without needing any tools. Simply unlock the cover buckle and flip it to the side to pull out the battery by the tab. The JAM² 8.7 is equipped with the Bosch System Controller and wireless Mini Remote.

  • Geometry for maximum fun on any type of trail.

The carbon frame with aluminum rear triangle makes the JAM² 8.7 light and agile. The motor and battery are perfectly integrated into the frame. This is how the JAM² 8.7 gets its sleek look. In addition, the battery is placed as low as possible in the down tube. This frame design optimizes the bike's center of gravity, making it much more stable on descents. The balanced and super agile geometry further contributes to the stability of the JAM² 8.7. The relevant bike parameters have been carefully evaluated so that they perfectly fit the intended use of the bike and guarantee fun on all trails. The low standover height ensures that you can also perfectly master technical terrain with your bike. By adjusting the headset cups, you can adjust the steering angle of your JAM² 8.7 individually according to your riding preferences from 65.5° to 64.5°.

  • Absolute control in every situation

When optimizing our F.O.L.D. (FOCUS Optimised Linkage Design) technology for our JAM² 8.7, it was extremely important to create responsive kinematics and suspension for absolute control - whether you're riding a technical or flow trail, up or down. The wide and grippy 29" tires improve traction on any type of surface, while you can always rely on strong brakes. Thanks to the good dosing of the brakes you can reduce your speed precisely and with high reliability.

More Information
More Information
Genuine number663512030
Permissible total weight150 kg
Bicycle typeE-bike / pedelec
Licensing/registration required acc. to road traffic regulations?No
ColourBlack, Gray
Frame ShapeFullsuspension
Frame designFull suspension MTB frame
frame materialCarbon
Frame featuresCarbon front triangle, aluminium rear triangle, 150 mm F.O.L.D. GEN2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm
Engine manufacturerBosch Performance Line CX Smart System, 36 V / 250 W / 85 Nm
Battery 625 Wh
DisplayBosch System Controller + Mini Remote
fork typesuspension fork
Fork DVO Diamond E3, 110x15 mm, 44 mm rake
Shock absorber type Rock Shox Deluxe Select, 210/55 mm, hardware: 25.0 x 25.0 mm
Number of gears12
Shifting system type SRAM NX Eagle, 12-speed
Shift leverSRAM SX Eagle, 12-speed
Cassette SRAM PG-1230 NX Eagle, 12-speed
CranksetSamox EC40 ISIS
Inner bearingIntegriert in Mittelmotor
Chain SRAM SX Eagle, 12-speed
Handlebar typeAluminium, 800 mm, rise: 30 mm, backsweep: 9°
Stem FOCUS C.I.S. 2.0 MTB integrated, 35 mm, aluminium
HeadsetACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset
SaddleSelle Royal Groove SRX
Seat post type Post Moderne dropper post PM-214, 34.9 mm
braking systemHydraulic disk brake
Brake lever type SRAM GUIDE T
Front hub typeNovatec D041, 15x110 mm
Rear hub typeNovatec D462, 12x148 mm
RimsRaceFace AR30 Offset
Rim size29 inches
TyresMaxxis Minion DHF, 2.6 Dual EXO TR, 66-622
